Description
Reliable engine components casted by full set of German equipment of casting system.
German HELLER parts machining production line ,online detection, automatic compensation, achieving
the height of the automatic and intelligent integration.
Intelligent flexible assembly & debugging production line, get the key data in a timely manner, monitoring
the entire production process, life-cycle. Data management TRP material system and MES manufacturing
execution system are responsible for
achieving the perfect unity of productive efficiency and productquality.
Assemble and machine production workshop keeps constant temperature and cleanness to lay the
foundation of excellent quality products.
|
Name |
Main marine propulsion engine |
||||
|
Model |
MC11.40C01 |
MC11.38C01 |
MC11.38C02 |
MC11.27C01 |
MC11.19C01 |
|
Order NO. |
MC1140C01 |
MC1138C01 |
MC1138C02 |
MC1127C01 |
MC1119C01 |
|
Type |
in-line, water cooled, four stroke, turbocharged-intercooled, high press common rail |
||||
|
Cylinder NO. Bore× Stroke mm×mm |
6×120×155 |
||||
|
Displacement L |
10.518L |
||||
|
Rated power / speed kW/r/min |
294/1900 |
279/1800 |
279/1500 |
200/1800 |
140/1800 |
|
overload power / speed kW/r/min |
323/1957 |
307/1854 |
279/1545 |
220/1854 |
156/1854 |
|
idle r/min |
600rpm |
||||
|
Max. idle stable speed r/min |
2090 |
1980 |
1650 |
1980 |
1980 |
|
stable adjusting rates |
10% |
||||
